Setting up and installing a load cell correctly is key to accurate weight measurements in industrial applications.
Whether you’re working with silos, tanks, or complex weighing systems, proper load cell setup can mean the difference between good data and costly measurement errors.
Let’s get into everything you need to know about load cell installation and setup.
Understanding Load Cells
At its simplest, a load cell is a transducer that converts physical force into an electrical signal. Think of it as the heart of your weighing system – it needs power to work and communicates through electrical signals via its cable.
Massload’s load cells, like most industrial grade cells, have two main wire pairs: excitation wires that power the internal Wheatstone bridge circuit and signal wires that carry the measurement data.
The typical analog output signal needs some sort of amplification device for practical use. Some advanced models also have additional sense wires that help compensate for excitation voltage drops across long cable runs so you can have accurate measurements in large scale installations.
Pre-Installation Planning
Before starting your load cell setup, planning is crucial. Here’s what you need to consider:
- What’s your attachment method (threaded connections, surface mounting, or rod-end bearings);
- Choose your mounting hardware and plates;
- Think about the load direction and choose between live-end and dead-end designs;
- Calculate the maximum expected load, including dynamic forces and safety factors;
- Consider environmental factors like temperature, moisture and vibration.
Guide to Load Cell Installation and Mounting
To know how to set up a load cell, it’s important to follow the installation steps carefully. These steps may vary depending on the type of load cell you’re using. Here’s a detailed guide for the most common types:
Single Point Load Cell Installation
Surface preparation:
- Clean the surface thoroughly;
- Surface must be level within 0.1mm;
- Mark the mounting hole positions.
Mounting steps:
- Mount the fixed end (dead end) to the base first;
- Install any required mounting hardware or plates;
- Align the load introduction point;
- Tighten mounting bolts to specified torque values;
- Connect cables with proper strain relief.
Setting up S-Type/Tension Load Cells
Pre-installation checks:
- Check rod end bearings or clevises are the correct size;
- Verify upper and lower mounting points are aligned;
- Check for clearance throughout the range of motion.
Mounting:
- Install upper mounting hardware;
- Attach load cell with pins or clevises;
- Secure lower mounting point;
- Check for free movement without binding;
- Install safety cables if required by regulation.
Compression Load Cell Setup
Base preparation:
- Install load button or mounting plate if required;
- Mounting surfaces must be flat and parallel;
- Clean all contact surfaces.
Installation steps:
- Install base plates or load distribution plates if required;
- Position load cell with arrow pointing to load direction;
- Install top plate parallel to base plate;
- Add anti-rotation devices if required;
- Check for even contact across all surfaces.
Tank/Hopper Load Cell Configuration
Initial setup:
- Install mounting assemblies at all support points;
- Level the existing support structure;
- Prepare wiring conduits.
Load cell mounting:
- Install check/stay rods for lateral stability;
- Mount load cells in mounting assemblies;
- Install top plates parallel to each other;
- Add anti-lift devices where required;
- Connect junction boxes and wiring.
Installing Beam Load Cells (e.g., in Truck Scale)
Foundation preparation:
- Concrete foundation must meet strength requirements;
- Install anchor bolts as per specification;
- Level surface.
Mounting sequence:
- Install base plates with grouting;
- Mount load cell with alignment marks;
- Install top plate and loading structure;
- Add lateral restraints if required;
- Complete electrical connections.
Extra Installation Tips
For all types of load cells:
- Handle with care to avoid damage;
- Never weld near an installed load cell;
- Protect cables from physical damage and electromagnetic interference;
- Install lightning protection for outdoor use;
- Record all installation parameters and calibration data.
Common Installation Mistakes to Avoid when Setting up Load Cells
During load cell installation and setup, several critical mistakes may happen that can affect system accuracy and life.
One big mistake that is often made is having the incorrect orientation during installation. Despite clear manufacturer specifications, technicians sometimes forget to check the load direction arrow and end up with inaccurate measurements.
Surface irregularities are another big issue in load cell installation. Assuming minor surface imperfections are okay can result in big measurement errors. Massload’s technical specifications emphasize the need for proper mounting accessories to address these
irregularities, as even small deviations can affect long-term performance.
For outdoor installations, environmental forces require special attention. Lack of anti-tilt protection in silo and tank monitoring applications can cause measurement drift and system failure when exposed to environmental stresses like wind load and structural vibration.
Environmental interference protection is another big consideration. Inadequate shielding during installation can compromise measurement integrity. This is especially true in industrial environments where multiple electrical systems are near the load cell installation.
Best Practices for Load Cell Setup
Professional load cell installation requires following some basic rules. The support structure is key; it must be solid to ensure measurement accuracy. Proper structural engineering ensures the foundation can support static and dynamic loading conditions.
Fastener installation requires attention to torque specifications. Professional installation protocols demand to follow manufacturer’s specified torque values and avoid torsional stress on the sensor body. Massload provides torque specifications for each load cell model to ensure proper installation.
The surface preparation method affects measurement accuracy. Professional installation requires thorough cleaning and preparation of all mounting surfaces to the manufacturer’s specifications. This attention to detail ensures good contact and load transfer between parts.
Documentation and record-keeping are part of professional load cell installation. Keeping records of installation parameters, calibration data, and system specifications will make future maintenance and troubleshooting easier. This should include initial calibration values, mounting specifications, and system configuration.
Preventive maintenance is key to system accuracy. Professional installation should have a defined maintenance schedule, including regular calibration verification, hardware inspection, and systematic evaluation of all system components. This proactive approach will identify potential issues before they affect system performance.
